Getting Started with Arduino and PA-12

Getting Started with Arduino and PA-12

David Eidelshtein
David Eidelshtein
PA Engineer

The PA-12 is a high precision actuator that can be controlled with Arduino. This PA-12 introduction guide will feature control methods and implementation with the PA-12 Arduino API.

There are two versions of the PA-12. The PA-12-R has a coreless DC servo motor and RS-485 communication protocol. The PA-12-T has a cored DC servo motor and TTL/PWM communication protocol.

Getting started with the PA-12 and Arduino will depend on the version of PA-12 that is being implemented. In this tutorial, the PA-12-10645012R is used – 1.06” Stroke, 4.50LBS of force, 12VDC coreless DC motor. The coreless motor signifies that the communication protocol for this actuator is RS-485.

The Arduino Leonardo/Uno does not have RS-485 communication protocol, but it does have TTL. We will be using a TTL to RS-485 module to communicate with the linear actuator Arduino in this tutorial.

Arduino Module

Figure 1 - RS-485 to TTL Arduino Module


PA-12 Control Operation

The PA-12 is controlled directly with data packets sent through TTL or RS-485 communication. Each data packet contains information that is used to perform a certain function of the PA-12 or to receive the current state of the device. The current state of the device could be, for example, the servo ID, voltage value, position of the actuator’s rod, etc.

Equipment and Software

PA-12 API

The PA-12 API can be downloaded here. This API contains the following files and folders:

  • PA12.ino
    • Contains the PA-12 command structures and functions that transfer and receive data to/from the PA-12
    • All functions that are used within the sample codes or will be implemented in your code are stored within this file
  • PA12.h
    • The header file contains the communication protocol and serial communication header files
    • Contains function and variable declarations for all PA12 features and functionality
    • setPosition, ServoID, presentSpeed, forceEnable
  • Utility Files
  • Sample Codes
    • The sample code can be used to easily implement PA-12 control into your own system
    • All sample codes are programmed for use with Arduino Leonardo, however, the variables used for the transmit and receive pins can be altered to be compatible with the microcontroller/Arduino that you already have

To Import PA12 Library

Select ‘Sketch’ --> Include Library --> Add.ZIP Library. All files located in the PA12 folder will be imported directly into the linear actuator Arduino library. This will then allow you to use the PA12 functions to control the actuator.

Arduino Library

Figure 2 - Arduion Library Import


Available Commands for PA-12

A table of commands are displayed below. For more info on the commands, review the PA12.ino for coding information. We will be covering the basic commands in this tutorial. Future tutorials will include more advanced functions and control techniques.

Read Functions

The functions located in the table below are read-only and return a value.

Read Function

Variable

Description

myServo.getModelNumber(ID_NUM)

ID_NUM

PA-12 model number

myServo.Version(ID_NUM)

ID_NUM

PA-12 motor version number

myServo.CalStroke (ID_NUM, *Length*)

ID_NUM, Length = Short, Long, or Center

Stroke position calibration check

myServo.presentVolt((ID_NUM)/10)

ID_NUM

Input voltage check

myServo.presentTemperature(ID_NUM)

ID_NUM

Current temperature of motor

myServo.MaxTemperature(ID_NUM)

ID_NUM

Read the maximum temperature limit

myServo.presentPosition(ID_NUM)

ID_NUM

Current position of the actuator

myServo.moving(ID_NUM)

ID_NUM

Returned value of motor status. 1 = Moving, 0 = Stopped

myServo.limitVolt(ID_NUM, *Highest/Lowest*)

ID_NUM,  High Voltage Level = Highest or  Low Voltage Level = Lowest

Read the high or low voltage setting

myServo.alarmLed(ID_NUM)

ID_NUM

Reads the status of the alarm LED. 1 = ON, 0 = Off

myServo.alarmShutdown(ID_NUM)

ID_NUM

Reads the status of the alarm shutdown mode

myServo.StrokeLimit(ID_NUM, *Long/Short*)

ID_NUM, Extend Limit = Long or Retract Limit = Short

Reads the max and min stroke limits

myServo.ResolutionFactor(ID_NUM)

ID_NUM

Reads the servo motor resolution factor

myServo.movingSpeed(ID_NUM)

ID_NUM

Reads the value of the servo motor speed

myServo.forceLimit(ID_NUM)

ID_NUM

Reads the max force of the servo motor (Volatile Setting)

myServo.maxForce(ID_NUM)

ID_NUM

Reads the max force of the servo motor (Non-Volatile Setting)

Write Functions

Write Function

Variable

Description

myServo(&Serial, enable_pin, Tx Level)

Serial port number, enable pin, transmission pin

Communication port setting

myServo.begin(*Baud Setting Value*)

Baud Setting Value (Refer to Table)

Serial communication Baud Rate

myServo.ServoID(ID_NUM, ID_Sel)

ID_NUM, ID_Sel

Change servo ID value

myServo.ledOn(ID_NUM, *LED RGB Value*)

ID_NUM, LED RBB Value (Refer to Table)

Turns on a specified LED

myServo.MaxTemperature(ID_NUM, Temperature)

ID_NUM, Temperature

Write the maximum temperature limit

myServo.goalPosition(ID_NUM, *Position Value*)

ID_NUM, Position Value (Refer to Table)

Set a desired stroke position

myServo.limitVolt(ID_NUM, *Highest/Lowest*, LimitVolt)

ID_NUM, Higher Value = Highest or Lower Value = Lowest, LimitVolt

Set the high or low voltage setting

myServo.alarmLed(ID_NUM, *Alarm Variable*)

ID_NUM, Alarm Bit

Alarm LED Setting. Refer to table for more info.

myServo.alarmShutdown(ID_NUM, *enable*)

ID_NUM, Enable: 0 = off, 1 = on

Motor alarm shutdown setting. If alarm is activated, the motor can be shutoff

myServo.StrokeLimit(ID_NUM, *Long/Short*, *Position Value*)

ID_NUM, Extend Limit = Long or Retract Limit = Short, Position Value (Refer to Table)

Writes the max and min stroke limits

myServo.ResolutionFactor(ID_NUM, *Resolution Factor*)

ID_NUM, Resolution Factor (Refer to table)

Sets the resolution value for actuator stroke positioning.

myServo.movingSpeed(ID_NUM, *Moving Speed Value*)

ID_NUM, Moving Speed Value (Refer to table)

Sets the speed of the servo motor

myServo.forceLimit(ID_NUM, *Force Value*)

ID_NUM, Force Value (Refer to Table)

Sets the max force of the servo motor (Volatile Setting)

myServo.maxForce(ID_NUM, *Force Value*)

ID_NUM, Force Value (Refer to Table)

Sets the max force of the servo motor (Non-Volatile Setting)


Variable Settings

The tables below contain the variable value that will be entered into the functions.

Baud Rate

Baud Variable Value

Baud Rate

16

115200

32

57600

64

19200

128

9600


LED Value

LED RGB Value

RED

GREEN

BLUE


Servo ID

Servo ID Value

0

1 - 253

254


For Servo Motor ID variable ID_NUM: A total of 255 options are available. The value of 0 is the default setting. You may select a value from 1 to 253 for an individual ID. The value of 254 is reserved for a broadcasting ID, therefore activating all PA-12’s located within a network.

Alarm Settings

Alarm Setting

Alarm Setting Value

Input Voltage Error

0

Stroke Limit Error

1

Range Error

3

Checksum Error

4

Overload Error

5

Instruction Error

6

*Reserved*

7

Stroke Resolution Factor

Resolution Factor Value

Resolution

1

4096

2

2048

3

1024

4

512


The higher the resolution value, the higher positional accuracy.

Moving Speed

Moving Speed Value

Speed Setting

0

Max Speed

1 - 1023

1 = Lowest, 1023 = Highest


Force Value

Force Value

Force Setting

0 - 1023

1 = Lowest, 1023 = Highest


Position Value

Position Value

Position

0 - 4095

0 = Fully Retracted, 4095 = Fully Extended


Wiring Guide

The PA-12 is connected to the RS-485 module, which is then directly connected to the Arduino. This version of the PA-12 requires a 12VDC power supply for the servo motor power.

Servo Motor

RS-485 Side A Arduino
DI Pin 1
DE Pin 2
RE Pin 2
R0 Pin 0



Pin 0 on the Arduino is the TTL receive. Pin 1 on the Arduino Leonardo is the TTL transmit. Pin 2 within the sample codes are set up such that they are used as the enable pin.

PA-12 4-Pin Connector

Value

Black

GND

Red

Servo Motor +VDC

White

Communication Pin A

Yellow

Communication Pin B



Port Connections - PA-12

Figure 3- PA-12 Port Connections

RS-485 Side B

Connection

VCC1

+5VDC (Arduino)

A

PA-12 White Wire

B

PA-12 Yellow Wire

GND2

Power Supply GND and PA-12 GND

1The RS-485 module receives power from the Arduino’s +5VDC output.

2The ground is shared between the PA-12, power supply, and RS-485 module.

Sample Code

In this tutorial, we will display three sample codes which provide preliminary insight into some of the PA-12’s features, and how the write and read functions can be implemented into your own code.

  1. PA12_PresentPosition
  2. PA12_StrokeLimit
  3. PA12_ForceLimit

1. Present Position

In this code, the user will enter a desired position value between 0 to 4095 within the serial monitor. Once entered, the command is sent to the PA-12 which will then activate the servo motor to move the rod to the desired position. While the motor is in motion, the present position will be displayed until the final position has been reached.

Arduino Code

2. Stroke Limit

Within this code, the PA-12 cycles every 1000ms within the inputted extension and retraction limit parameters. The Long and Short designations located in the stroke limit function

Arduino Code

3. Force Limit

The force limit code being displayed here is the volatile version. This means that each time the PA-12 loses power, the force limit value will be reset back to its default setting. The user will enter the force limit value from the serial monitor. In this case, the maximum force value of 0 signifies a low force value, and 1023 signifies a maximum force value.

Arduino Code

Future Tutorials

In future tutorials we will be covering:

  • Advanced function implementation
  • TTL and PWM version PA-12 Control
  • Troubleshooting Techniques
  • External control methods

The PA-12 is a versatile and highly precise actuator that allows the end-user to achieve direct control over their application. With the right implementation, the PA-12 is able to accomplish exactly what your system requirements may be.

For additional information, please send us an email at sales@progressiveautomations.com, or give our team a call at 1-800-676-6123.
