High Load Linear Actuator - Optional Feedback
Model: PA-HD1
The PA-HD1 is a cost-effective heavy duty linear actuator, pushing and holding up to 1,574 lbs dynamic and 2,248 lbs static with a stainless steel shaft and metal gears. IP65 rated to withstand dust, water jets, and splashes in harsh environments.
Couldn't load pickup availability
Overview
[PA-HD1]
The PA-HD1 High Load Linear Actuator is designed for applications that require high force, durable construction, and dependable linear motion in demanding environments. Its stainless steel shaft and metal gears deliver up to 1,574 lbs of push and pull force and up to 2,248 lbs of static holding force. An IP65 protection rating provides protection against dust and exposure to water jets or splashes, while the heavy-duty construction supports use in harsh industrial environments. A Hall Effect feedback version is also available for applications that require position feedback.
Technology
Specifications
The PA-HD1 combines high-force performance with multiple voltage, speed, and current configurations to support a wide range of heavy-duty automation requirements. Available configurations allow you to select the appropriate balance of load capacity, travel speed, and power consumption for your application.
| Voltage | 12 VDC | 24 VDC | 12 VDC | 24 VDC | 12 VDC | 24 VDC |
| Dynamic Force | 450 lbs | 450 lbs | 899 lbs | 899 lbs | 1574 lbs | 1574 lbs |
| Static Force | 899 lbs | 899 lbs | 1574 lbs | 1574 lbs | 2248 lbs | 2248 lbs |
| Speed - No Load | 1.37 "/sec | 1.37 "/sec | 0.66 "/sec | 0.66 "/sec | 0.33 "/sec | 0.33 "/sec |
| Speed - Full Load | 1.11 "/sec | 1.11 "/sec | 0.55 "/sec | 0.55 "/sec | 0.27 "/sec | 0.27 "/sec |
| Current - No Load | 3.5 A | 1.8 A | 3.5 A | 1.8 A | 3.5 A | 1.8 A |
| Current - Full Load | 18.0 A | 10.0 A | 18.0 A | 10.0 A | 18.0 A | 9.0 A |
The PA-HD1 High Load Linear Actuator is designed for integration into systems where high force, durability, and environmental protection are important. Its stainless steel shaft, metal gears, and IP65-rated construction support reliable operation across demanding industrial and outdoor applications.
Refer to the Product Specifications table for dimensions, duty cycle, environmental rating, connector type, materials, stroke options, operating conditions, and other technical specifications.
*Please note that the PA-HD1 is not rated for shock or pulse loads.
Complete your PA-HD1 High Load Linear Actuator system with compatible mounting and control components. Due to the actuator's high-force and current requirements, selecting appropriately rated accessories is important for reliable operation.
MOUNTING BRACKETS:
The PA-HD1 is compatible with the BRK-17 mounting bracket, designed for Heavy Duty Actuators and high-load applications. Refer to the corresponding product page for additional specifications and installation information.
CONTROL SYSTEMS:
The PA-HD1 is compatible with a range of Progressive Automations control systems, provided the selected controller and supporting components meet the actuator's voltage and current requirements. Refer to the compatibility tables to select the appropriate control box, controller, relays, and other required components for your application.
