Solar Hall Effect Sensor Actuator IP66
Model: PA-100
In stock
Ships within 24 hours
solar actuator
Solar Hall Effect Sensor Actuator IP66
Solar Hall Effect Sensor Actuator IP66
Solar Hall Effect Sensor Actuator IP66
In stock
Ships within 24 hours

Solar Hall Effect Sensor Actuator IP66

Model: PA-100
Instant Quote
Regular price
$574.99
Sale price
$574.99
7-9 units
10-19 units
20–49 units
Stroke *
Force *
Speed *
Quantity
-
+

Specifications

The PA-100 Solar Actuator is designed specifically for solar applications. It can produce up to 3,300 lbs of force, so it is able to handle the high force requirements needed for large solar machinery. It also features welded shaft mounts to make installation onto solar trackers simple. The high environmental protection rating produces a durable unit able to withstand potentially harsh outdoor environments where most solar applications are found.

This unit can be found primarily in the solar power industry. For a full list of specifications, customization options, and dimensional drawings, please see our PA-100 Data Sheet.

MOUNTING OPTIONS:

The solar linear actuator has mounts welded onto the shaft of the unit so it can be easily mounted to solar trackers and other solar applications.

BROWSE MORE ACTUATORS

PA-100 Specifications
Input Voltage:
24 VDC
Stroke:
18-36 inches
Force:
3300 lbs
Speed:
0.06"/sec
Protection Class: i
IP66
Feedback:
Yes
Operational Temperature:
-30ºC to +70ºC
Noise: i
db<56(A)
Duty Cycle: i
12%
Limit Switch:
Internal, Non-Adjustable
Current (full load):
6A
Mounting Holes:
0.75"
Motor Type:
Brushed DC Motor
Screw Type:
ACME
Housing Type:
Aluminum Alloy
Fully Retracted:
13.37" + stroke (see PDF for variations)
Fully Extended:
13.37" + stroke + stroke (see PDF for variations)
Certifications:
UL
Unit Weight:
24.23 lbs
Warranty:
18 Months
Data Sheet
3D Models
Dimensional Drawing
Dimensional Drawing

Warranty
Warranty

We at Progressive Automations are committed to manufacturing and selling products of the highest quality. Each of our products are manufactured at our state-of-the-art facility and undergo rigorous quality control procedures and checks throughout the production process and prior to being shipped to the customer.

Depending on the product you purchase the warranty period may vary. Our Mounting Brackets and Table Lifts come with a 60-month warranty, while the rest of our products are available for an 18-month warranty period. If a product becomes defective within the warranty period and is used within its rated parameters and environmental conditions, we will replace or repair the product at no cost.

For more information on our Warranty terms click here.
